Double Layered Rolled Sugar Cone Production Line GELGOOG
| Model | GG-DCL45×2-18 |
| Capacity | 4000-4500pcs/h |
| Voltage | 380v 50hz 3phase |
| Size | 8000*800*1850mm |
Features
Description of Automatic Sugar Cone Production Line
This sugar cone line is a quality machinery specially developed by GELGOOG factory for the production of crispy sugar cones. Each mold has double baking pans, which can bake two biscuit sheets in one time.
The baking molds is ductile iron materials, which heats up quickly and does not stick to the ice cream cones. And one hour can process the sugar cones in good appearance and one hour can make 1500-7500 pieces.
This sugar cone line is a quality machinery specially developed by GELGOOG factory for the production of crispy sugar cones. Each mold has double baking pans, which can bake two biscuit sheets in one time.
The baking molds is ductile iron materials, which heats up quickly and does not stick to the ice cream cones. And one hour can process the sugar cones in good appearance and one hour can make 1500-7500 pieces.
Characteristics of Rolled Sugar Cone Production Line
♣ The batter can be made according to your own ice cream cone recipe and we also provide the recipe.
♣ This automatic sugar cone line is easy to operate, and easy to dismantle and easy to clean.
♣ Using high-quality materials, the life of the machine is improved, and there are fewer failures.
♣ This equipment with the high-power motor, large output, high efficiency in work.
♣ Save time and effort, it is the professional machinery used to make ice cream sugar cones.
Automatic sugar cone production line is suitable for baking high quality ice cream sugar cone with fully automatic operation. It makes rolled cone in unifirm size, and also can make round thin biscuit, bowl-shaped waffle basket. We can design the different baking machines to make different types of sugar rolled cones as required by clients.
Automatic sugar cone production line is suitable for baking high quality ice cream sugar cone with fully automatic operation. It makes rolled cone in unifirm size, and also can make round thin biscuit, bowl-shaped waffle basket. We can design the different baking machines to make different types of sugar rolled cones as required by clients.
How to Operate GELGOOG Sugar Cone Processing Line?
Precautions of Using Sugar Cone Line
1. The smallest sugar cone's size that can be made: the smallest can only be 6cm in height and 2.8-3cm in diameter.
2. On a baking tray, you can make both flat-sided egg cones and natural-sided cones. The conventional size of flat-sided cones is 11-12cm, and the natural edge can be less than 15cm.
3. Regarding the recipe: Our factory can provide users with recipes for making cones. If you are a new business person, don't worry.
Technical Data
| Model | Baking plate size(mm) | Voltage | Power | Capacity | Cone length | Size | Weight |
| GG-DCL35×2-18 | 300×320 | 380v 50hz 3phase | 3kw | 1500-2500pcs/h | ≦125mm | 6*0.8*1.85m | 6T |
| GG-DCL37×2-18 | 300×320 | 3kw | 3500-4000pcs/h | ≦125mm | 7*0.8*1.85m | 6T | |
| GG-DCL45×2-18 | 300×320 | 3kw | 4000-4500pcs/h | ≦125mm | 8*0.8*1.85m | 6T | |
| GG-DCL55×2-18 | 300×320 | 3kw | 4500-5500pcs/h | ≦125mm | 9*0.8*1.85m | 7T | |
| GG-DCL65×2-20 | 300×320 | 3kw | 6000-6500pcs/h | ≦125mm | 11*0.8*1.85m | 7T | |
| GG-DCL75×2-22 | 300×320 | 3kw | 6500-7500pcs/h | ≦125mm | 11*1.9*1.85m | 8T |
